Vertical Autoclave

• Chamber Size
• 22L (300 mm x 330 mm H)

• Chamber Thickness
• 3 mm (SS 304 grade)

• Design Pressure
• 2.2 kg/cm2

• Design Temperature
• 134C

• Door Type
• Radial locking lid

• Heat Uniform
• 1C at 121C

• Insulation
• Double wall with insulation

• Net Weight
• Approx. 38 kg

• Outer Size
• 410 x 320 x 560 mm

• Piping System
• Stainless steel internal

• Power Consumption
• 5 kW

• Recording Parameters
• Manual or USB data logger (optional)

• Spraying Piping
• Stainless steel

• Steam
• Electric boiler generated

• Sterilization Time
• 0 - 60 minutes adjustable

• Sterilizing Temperature
• 121C

• Temperature Scope
• 105C - 134C

• Type
• Other, Vertical Autoclave

• Valves
• Safety, release, and drain

• Working Pressure
• 1.2 kg/cm2

• Working Temperature
• 121C

• Chamber Size
• 430 x 450 mm

• Chamber Thickness
• 5 mm (SS 304 Grade)

• Compressed Air
• 5-7 kg/cm2 required

• Design Pressure
• 2.3 kg/cm2

• Design Temperature
• 140C Max

• Door Type
• Single Hinged Door with Radial Locking

• Heat Uniform
• 1C throughout Chamber

• Inner Trolley
• Stainless Steel, Removable Type

• Insulation
• High Density Mineral Wool, 50 mm

• Net Weight
• Approx 145 kg

• Outer Size
• 650 x 560 x 1200 mm

• Outer Trolley
• Provided

• Piping System
• SS316, Seamless, with Safety Interlocks

• Power Consumption
• 6-9 kW

• Recording Parameters
• Digital Display with Printer Output

• Spraying Mode
• Rotary/Static Adjustable

• Spraying Piping
• SS 304/316 High Pressure, Removable

• Steam
• Automatic Steam Generation

• Sterilization Time
• 0 - 99 minutes, Programmable

• Sterilizing Temperature
• 121C - 134C

• Temperature Scope
• Omnidirectional Temperature Control

• Type
• Other, Vertical Cylindrical Autoclave

• Valves
• Premium Quality Safety & Exhaust Valves

• Working Pressure
• 1.2-1.5 kg/cm2

• Working Temperature
• Up to 134C
